Qualcomm Dragonwing QRB2210: Quad-core Arm Cortex-A53 @ 2.0 GHz Adreno GPU 3D graphics accelerator 2xISP (13 MP+13 MP or 25 MP) @ 30 fps

STM32U585 Arm Cortex-M33 up to 160 MHz 2 MB flash memory 786 KB SRAM

2GB LPDDR4

From USB-C connector 5 V max at 3 A Input Voltage (VIN): 7-24 V

16GB eMMC

1xUSB-C port with host/device role switching, power role switch and video output

Wi-Fi 5 2.4/5GHz with onboard antenna Bluetooth 5.1 with onboard antenna

I2C/I3C, SPI, PWM,CAN,UART, PSSI, GPIO, JTAG, ADC

Video output support via USB-C MIPI DSI pins on JMEDIA header

4xRGB user-controllable LEDs,8x13 Blue LED Matrix,1xQwiic connector voltage 3V3, I2C, 1xUser push-button, JCTL: MPU Remote Debug connector

Microphone IN / Headphone OUT / Line OUT on JMISC

68.85 mmx53.34 mm (UNO form factor)

Linux Debian OS with upstream support

Arduino Core on Zephyr OS

Docker and Docker Compose support

Windows: Windows 10 or later (64-bit), macOS: macOS 11 or later (64-bit), Linux: Ubuntu 22.04 or later, and Debian Trixie (64-bit)
